ALLMAN 5-Ton Electric Chain Hoist with Motorized Trolley

Tips: Full engineering drawing with key dimensions and beam flange range available upon request.

• Manufacturing Workshop Engine assembly. Mold handling. Machine tool loading. With the optional dual-speed control, operators get precision inching for tight-tolerance positioning — then full speed to keep production moving.
• Warehouse & Logistics Palletized goods lifting. Rack replenishment. Loading bay operations. The motorized trolley lets a single operator cover the entire bay without pushing a suspended load by hand.
• Steel & Metal Processing Coil handling. Plate positioning. Fabrication bay lifting. G80 chain and 125% overload protection handle the impact and shock loads common in steel service centers.
• Automotive & Assembly Line Body-in-white transfer. Sub-assembly lifting. Station-to-station movement. CE-certified electrical safety and emergency stop protection for manned production environments.

Tips: Lifting something outside these examples? Tell us your load, lift height, and duty cycle — we'll confirm the right configuration.

Introduction: The standard 5-ton model fits most applications. When your site demands something different, we build to match. Customization Options:

• Lifting Height Standard: 3 meters. Extended: 6 m / 9 m / 12 m / up to 30 m. Tell us your hook path — we'll supply the right chain length and container.
• Travel Speed Single-speed for straightforward lifting. Dual-speed (fast/slow) for applications requiring inching control — mold alignment, engine mating, precision assembly.
• Beam Fit Trolley flange adjustment range custom-matched to your existing I-beam dimensions. No field modifications required.
• Corrosion Protection Standard indoor finish for most factory environments. Upgrade to C4 or C5 anti-corrosion coating for coastal installations, chemical plants, or outdoor service.
• OEM / ODM Nameplate engraving, body printing, user manual, and packaging — all produced under your brand identity.

Nantong Allman Industry Co., Ltd. is a professional manufacturer and exporter of lifting equipment. With more than 20 years of industry experience, we focus on the research, development and production of electric winches, electric chain hoists, manual winches, manual chain hoists and related lifting accessories.

We are committed to providing high-quality products, stable performance and reliable after-sales service. We offer customized OEM/ODM solutions to meet different requirements of global customers. Our products are well sold in Europe, South America, North America, Africa, Southeast Asia and other regions.

We aim to build long-term cooperative relationships with global partners based on mutual benefit and win-win results.

Our services:

Allman are aimed to provide customers a good solution, not just a product. We will try our best to offer any information you need.

• Products Inquiry: We have received your inquiry and will respond within 24 hours to ask for further details.
• Price List: After receiving the relevant information, we will provide you with a quote within 8 hours.
• Customization Service: We can also provide customized services to meet the different requirements of our various clients. For electric winches, if you have specific requirements regarding lifting capacity, rope material, etc., please feel free to contact us. We have a professional technical team that can draw up designs and develop solutions for you.
• Place orders & Production: Upon receiving your order confirmation, we will update the Proforma Invoice (PI) and place the order with the factory as soon as possible. We will provide you with real-time updates on the production process, including photos. Finished product photos and testing videos are also available upon request.
• Shipping & Delivery: After the products are manufactured, we will send you photos and prepare the relevant documents for you. We will also provide you with real-time tracking information so you can stay informed about the status of your shipment.

Q: What's the difference between single-speed and dual-speed?

A: Single-speed runs at one fixed lifting speed — ideal for straightforward material handling where precision isn't critical. Dual-speed adds a slow "inching" mode (typically 1/5 of full speed), which is essential for mold alignment, engine mating, and any task requiring millimeter-level control.

Q: What does G80 chain mean, and why does it matter?

A: G80 is an international grade standard with a minimum break stress of 800 N/mm². G80 chain is heat-treated, calibrated for precise pitch, and each link is proof-tested to 4× the working load limit. Lower grades (G43, G70) wear faster and carry higher risk under frequent heavy cycles — G80 is the industry benchmark for powered hoist applications.

Q: Can this hoist be used outdoors?

A: Standard IP54 protection handles occasional splashing and dust ingress. For permanent outdoor or coastal installation, we recommend upgrading to C4/C5 anti-corrosion coating and adding a rain cover for the motor housing. Share your site conditions with our team for a tailored recommendation.

Q: How do I determine the right beam flange width for the trolley?

A: Measure your existing I-beam flange width and thickness with a caliper. Our trolley has an adjustable range — provide the measurement when ordering. If you're designing a new beam system, we can recommend standard I-beam profiles that fit without modification.

Q: What are the MOQ and lead time?

A: Sample orders: 1 unit accepted. Bulk orders: 10 units MOQ. Lead time: 15–25 days for standard models, 25–40 days for custom voltage or extended lifting height configurations.

Q: Do you supply spare parts and after-sales support?

A: Yes. We stock load chains, brake discs, contactors, pendant controllers, trolley wheels, gear sets, and guide rollers. Spare parts ship within 3–5 working days. Technical support is available via email and WhatsApp throughout the warranty period and beyond.
