ALLMAN M5 0.5-5 Ton Electric Hoists – IP55 Motor Powered by Electric Trolley for Overhead Crane

Where can you use the AMS electric hoist?

**Automotive Manufacturing:** Precisely lifts engines and vehicle bodies; dual-speed control enhances assembly efficiency.

**Heavy Machinery Assembly:** M5 duty rating supports high-frequency, high-intensity continuous operations.

**Shipbuilding Industry:** IP54 protection combined with a cooling fan ensures adaptability to high-temperature, humid, and dusty environments.

**Logistics & Warehousing:** Traveling design paired with an electric trolley enables lateral movement along tracks, thereby expanding the operational radius.

What does it offer you?

Reduced downtime

Enhanced operational safety

Lower maintenance costs

Greater peace of mind and ease of use for operators

Description:

The AMS series is not just a hoist — it's a solution for real-world lifting challenges.

In automotive manufacturing, the AMS electric hoist is used for the precise lifting of engines, car bodies, and heavy components. Its dual-speed control allows operators to switch between fast positioning and fine-tuning, significantly improving assembly line efficiency while reducing the risk of product damage.

In heavy machinery assembly, where lifting tasks are frequent and intense, the AMS series delivers reliable performance with its M5 working class. It supports high-frequency, continuous operations without overheating or losing stability — helping you avoid unplanned downtime and costly delays.

In shipbuilding, the working environment is often harsh — high temperatures, humidity, and dust are common. The AMS hoist is built to withstand these conditions with IP54 protection and a built-in cooling fan, ensuring stable operation even in confined, demanding shipyard environments.

In logistics and warehousing, the AMS can be configured as a running type hoist with an electric trolley, allowing it to move horizontally along overhead tracks. This increases the working radius across the warehouse floor, reduces manual effort, and speeds up the movement of goods between storage and shipping areas.

For general industrial use, the AMS hoist helps you:

Reduce downtime with reliable, long-lasting components

Improve safety with electromagnetic braking and overload protection

Lower maintenance costs with high-strength 80-grade chains and wear-resistant gears

Increase operator confidence with smooth, quiet, and responsive controls

Whether you're lifting 500 kg or 5 tons, for 10 minutes or 10 hours a day — the AMS series is engineered to deliver consistent, dependable, and safe performance in your real working environment.

∗ ALLMAN uses the lifting motor with high-purity copper winding, dedicated for heavy duty electric hoist. AMS electric chain hoist come with two speeds as standard.

∗ With electro- magnetic brake, which could quickly and efficiently stop motor operating.

∗ Precision gear group of output gear, chain wheel, gear and gear shaft, running smoothly and with low noise.

∗ Transformer is used to provide safe control voltage in case of the unexpected accident.

∗ With a cooling fan, it could be a good heat dissipation.

∗ Inverse phase sequence protecting device is the special electrical equipment of electric chain hoist to prevent the motor from running when wired incorrectly.

Why do global customers choose ALLMAN?

20 years ago, we started from a not big factory, focusing on one thing: making lifting safer and more efficient.

Today, our products cover Asia, Europe, the Americas, and Africa. We still insist:

Every electric hoist undergoes 100% load testing before leaving the factory. Every customer enjoys a 1-year warranty.

Not because we're big, but because we've been doing it for a long time.

Exhibition

You can get a quote by contacting us using the following methods.

Email: [email protected]

Wechat/Whatsapp:+8613817585870

More Choices

Q1: Can the AMS electric hoist be used in humid or dusty environments?

A: Yes. The AMS series has an IP54 protection rating, and the motor is equipped with a cooling fan and Class F insulation.

Q2: What is the difference between the fixed type and the running type (with electric trolley)? How do I choose?

A:Fixed type: The hoist body is stationary, suitable for single-point lifting.

Travelling type: The hoist can move horizontally along the I-beam, ideal for applications that require covering multiple workstations.

If you need to operate along a track, choose the running type. If lifting is always at the same position, the fixed type is more economical.

Q3: Does the electric hoist require regular maintenance? How often?

A: We recommend a routine inspection every 500 working hours or every 3 months, including:

Chain wear condition

Brake sensitivity

Chain condition

Motor cooling fan cleanliness

We offer lifetime technical support — feel free to contact us anytime.

Q4: Can you provide CE certificates?

A: Yes. The AMS series comes standard with CE certification, and our factory is ISO9001 certified. Copies of the certificates can be provided after order confirmation.

Q5: Can I customize non-standard voltage or special lifting height?

A: Yes. In addition to standard 220V/380V/415V, we also accept non-standard voltage customization (e.g., 440V, 460V). Standard lifting heights are 3m/6m/9m, and custom heights are also available. Please contact us with your specific requirements.

Q6: Is it normal for the electric hoist to make noise during operation?

A: The AMS series uses precision gear sets to keep noise levels within industry standards. If you hear abnormal noise (e.g., sharp sounds or gear grinding), stop using the hoist immediately and contact us — it may indicate gear wear or foreign material inside.

Q7: Can I install it myself, or do I need a professional?

A: While installation is straightforward, we recommend professional installation, especially for the running type (with electric trolley), which involves track alignment and electrical connections. We provide a detailed instruction manual and can offer technical guidance if needed.
