Place of Origin: |
Jiangsu China |
Brand Name: |
ALLMAN |
Model Number: |
PNW |
Minimum Order Quantity: |
One pcs |
Packaging Details: |
Export-specific kraft paper cartons |
Delivery Time: |
According to your quantity |
Payment Terms: |
TT |
1. Suitable for many lifting and lowering applications such as raising boats on davits of raising and lowering sailboat keels.
2. Self-locking brake winches provide additional safety and control for many lifting and pulling jobs
3. The automatic fraction brake supplies constant, positive holding action and prevents runaway load.
4. Brake is fully automatic and the load remains in position anytime the handle is released.
5. Chrome Finished is available.
6. Can add wire rope and Make Stainless Steel look
Date Sheet:
|
Model |
PNW-100 |
PNW-300 |
PNW-500 |
PNW-1000 |
PNW-2000 |
PNW-3000 |
|
Capacity 1st Rope Layer(kg) |
100 |
300 |
500 |
1000 |
2000 |
3000 |
|
Required Efforts 1st Rope Layer(kg) |
11.5 |
11 |
12 |
12 |
13 |
18 |
|
Drum Capacity(m) |
30 |
30 |
40 |
40 |
40 |
40 |
|
Drum Diameter（mm) |
48 |
60.5 |
60.5 |
76.3 |
89.1 |
101.6 |
|
Wire Cable Diameter(mm) |
Φ5 |
Φ6.3 |
Φ6.3 |
Φ8 |
Φ9 |
Φ12.5 |
|
Reduction Gear Ratio |
1:1 |
2.88:1 |
4.33:1 |
12.19:1 |
22.68:1 |
22.16:1 |
ALLMAN INDUSTRY specialized in providing hand winch. We are highly experienced, get CE approved company. With more than 20-years rich experience, we have developed and produced different high quality manual hand winches for different applications for international quality product and very best customers service for the very best price from ALLMAN.
ALLMAN INDUSTRY believes the “ Quality & Safety” of our products and services is the most important value of the whole company. We always insist on providing high quality and safety, easy operation and installation, less cost on working and maintenance to our Global customers. ALLMAN never sacrifices our quality principle for cost competition. Our concentration and long working experience have helped us become a professional supplier in winch and hoist filed.
Most of ALLMAN Products have the CE certificate and ALLMAN company now has got the ISO certificate, Hand winches are no exception.. We can also provide the COO and the Test Report of the manual hand winch, so you don't need to worry about certification issues.
Q：Can you provide OEM service?
A：Yes. For ALLMAN manual winch you can make your own brand, your own color of the if you want.
Q：Min order quantity of the Brake Hand Winch：
A：1 unit is acceptable.
Q：Load time
A：For sample order we can finish the production of the manual winch in 5-7 days. For big order, we will finish the production in about 30 days. If your quantity of the hand winch is very big, we need to talk.
Q：Shipping methods of the manual hand winch?
A：By Air or By Sea. The nearest port to us is Shanghai.
Q：How to purchase the manual hand winch?
A：You can contact our sales via WhatsApp or Email.
Q：What is the payment methods?
